Features of PT208 ceramic pressure sensor
It's an advance pressure transducer than traditional mechanical pressure transducer.
2. ±2%FS small output error, including nonlinear, hysteresis error and repeatability, full temperature range.
3. Light weight and small size, convenient to install and operate.
4. It has complete surge voltage protection function.
5. Works for oil, fuel, diesel, gas, water, air pressure, can be used in oil tank, gas tank, diesel tank etc.
Specifications of PT208 ceramic pressure sensor
| suring Range | -1000KPa~0-60MPa |
| Compensation Temperature | -10~70℃ |
| Output Signal | 4-20mA;1-5V;0-5V;00-20mA;Customization |
| Medium Temperature | Customization |
| Ambient Temperature | -40~85℃ |
| Enclosure Protection | IP65 |
| Pressure Type | Gauge pressure; Absolute pressure; Seal pressure |
| Temperature Effect on Zero | ±0.03%FS/℃ |
| Sensitivity Temperature Drift | ±0.03%FS/℃ |
| Overload Pressure | 200%FS |
| Long-term Stability | ≤0.2%FS/℃ |
| Natural Frequency | 5KHz~650KHz |
Applications of PT208 ceramic pressure sensor
● HVAC system
● Water filter
● Air conditioner control equipments
● Frequency water supply
● Water pump
● Building water supply
Description of PT208 ceramic pressure sensor
PT208 series adopts high-quality stainless steel structure, the core and pressure sensor chip are imported from Germany, adopt digital calibration and compensation technology, and pass safety certification and CE certification. Widely used in on-site pressure measurement of compressors, automobiles, air conditioners, etc.
The pressure sensor product line offers different measurement principles, materials and displays to meet the requirements of various industrial manufacturing plant operations in the United States. For pneumatic applications, ceramic pressure sensor cells and piezoresistive measurement technology are used. The PT208 pressure sensor is resistant to dynamic pressure peaks and guarantees a high overload resistance even in the event of extreme pressure peaks, such as fast closing of valves. Electronic pressure sensors can prevent damage or downtime from wear and tear on mechanical moving parts, and last longer than traditional sensors with critical points of failure. Their applications range from simple monitoring tasks such as switching to precise digital pressure rating measurements.
It provides high-accuracy static pressure sensors and transducers for use in in commercial HVAC systems for room or space pressurization applications. These products are designed to provide critical measurements when assessing the static air pressure level outside or within a space. Our static pressure sensors and transducers are highly accurate, and the probes can sense the static pressure of the room, space, plenum or duct within 0.5% of the actual pressure value.
PT208 is widely used in:
Process control system Air compressor Refrigeration system
CNGSNG gas station Natural gas HVAC
Oil pumpdrilling Food industry Chemical industry
Hydraulic control system pump&water system Others
tance
